Dust Collector: Central Air Filtration for Industry
A Dust Collector is a large-scale air filtration system that captures, separates, and removes dust particles and contaminants from the air within industrial facilities.
Its primary purpose is to:
Improve Air Quality: Protect worker health and meet safety regulations.
Protect Machinery: Prevent damage to sensitive equipment.
Recover Product: Capture valuable reusable material from the airstream.
What Is a Mobile Dust Collector?
A mobile dust collector which is also known as a portable dust collector or mobile dust extractor that is an advanced air filtration system designed to capture and remove airborne dust, fumes, and fine particulates generated in various industrial processes. Unlike centralized dust collection systems, mobile units are compact, movable, and energy-efficient, offering flexibility for workshops, factories, and on-site environments where mobility and performance are essential.
Types of Mobile Dust Collector and Specifications
Type No. | Model | Airflow (m³/h) | Power (kW) | Filtration Efficiency | Filter Type | Features |
1 | MDC-1000 | 1000 | 1.5 | 99.9% | Cartridge | Compact & Light |
2 | MDC-2000 | 2000 | 2.2 | 99.9% | Cartridge | Ideal for Workshops |
3 | MDC-3000 | 3000 | 3.0 | 99.8% | Bag Filter | Medium Duty |
4 | MDC-4000 | 4000 | 4.0 | 99.9% | HEPA | Low Noise |
5 | MDC-5000 | 5000 | 5.5 | 99.9% | Cartridge + HEPA | Dual-stage Filter |
6 | MDC-6000 | 6000 | 7.5 | 99.95% | Cartridge | Industrial Grade |
7 | MDC-7000 | 7000 | 9.0 | 99.9% | Bag Filter | Continuous Operation |
8 | MDC-8000 | 8000 | 11.0 | 99.95% | Cartridge + Cyclone | Heavy-duty Use |
9 | MDC-9000 | 9000 | 13.0 | 99.98% | HEPA | Advanced Filtration |
10 | MDC-10000 | 10000 | 15.0 | 99.99% | Modular Filter System | Customizable Solution |
Mobile Dust Collector Material Properties
Senotay’s mobile dust collectors are constructed from premium-grade materials to ensure long-term reliability:
Body Material: High-strength carbon steel or stainless steel with anti-corrosion coating.
Filter Media: Industrial-grade polyester fiber or PTFE-coated filter cartridges for high efficiency.
Frame & Wheels: Powder-coated steel frame with heavy-duty caster wheels.
Surface Treatment: Epoxy powder coating for extended durability in harsh environments.
Mobile Dust Collector — Technical Specification Table
Physical Dimensions | Performance Ratings | Material & Construction | Operational Data | Certifications & Lifecycle |
Length: 650–1,400 mm | 1,000–6,000 m³/h | HEPA / PTFE / Polyester | 220V / 380V | : 5–10 years |
Width: 500–950 mm | 99.5% @ 0.3 μm | SS304 / Carbon Steel | 1.1–7.5 kW | 300,000+ |
Height: 1,000–2,200 mm | 1,500–3,200 Pa | 1–4 pcs | 68–78 dB(A) | ISO 9001 / CE |
Wheel Diameter: 100–200 mm | 80 °C | EPDM / Silicone | 0–60 °C | EN 60204 |
Ø: 150–250 mm | -1.2 to -3.5 kPa | GI Steel / SS304 | Pulse Jet / Manual Shake | ≤ 5 mg/m³ |
No. of Lifting Points: 2–4 | 18–30 m/s | 1.5–3.0 mm | 80–320 kg | 12–24 months |
Caster Count: 4 pcs (2 braking) | Continuous | PVC / PU | 3–8 m | IP54–IP55 |
Handle Height: 900–1,100 mm | ≥ 99% | GI / SS | Manual Push | EN 12779 |
How It Works – Working Mcchanism
The mobile dust collector operates by drawing contaminated air through a powerful suction system. The air passes through multi-stage filtration, typically a pre-filter followed by a high-efficiency filter (HEPA or cartridge):
Air Intake: The suction hood captures airborne particles.
Filtration: Dust-laden air is filtered through sequential filtration stages.
Collection: Dust accumulates in the collector hopper or dust bin.
Clean Air Discharge: The purified air is released back into the workspace.
The design ensures continuous operation, low maintenance, and environmental compliance.
Mobile Dust Collector Installation Method
Mobile dust collectors are designed for quick and simple installation:
1. Position the Unit
Place the dust collector near the dust-generating source.
2. Connect Flexible Suction Arm / Hose
Adjust the extraction arm for optimal capture efficiency.
3. Check Power Supply
Connect to the appropriate power source (110V/220V/380V depending on configuration).
4. Start and Adjust suction
Switch on the unit and adjust airflow based on application.
5. Routine Maintenance
Empty the dust bin, inspect filters, and ensure smooth wheel movement.
No complex installation or ducting is required, making it ideal for temporary and mobile operation
Standard Physical & Mechanical Properties of Mobile Dust Collector
Property | Specification | Description |
Airflow Capacity | 1000–8000 m³/h | Adjustable for different applications |
Filtration Efficiency | ≥99.9% | Captures fine particles and micro-dust |
Noise Level | <75 dB | Low-noise operation |
Voltage | 380V / 220V | Customizable for site requirements |
Filter Type | Cartridge / Bag | High-efficiency industrial filter elements |
Structure | Mobile / Compact Modular | Easy relocation and maintenance |
Power | 1.5–15 kW | Energy-efficient motors |
Why It’s Important to Invest in a Mobile Dust Collector
Investing in a Senotay mobile dust collector means safeguarding your workforce, production efficiency, and compliance with modern environmental health standards. Benefits include:
Environmental compliance with ISO and CE standards.
Reduced downtime through efficient dust control.
Portable versatility for multiple workstations.
Energy efficiency from optimized airflow design.
Cost-effectiveness through long filter life and minimal maintenance.
Technical Advantages in Manufacturing Mobile Dust Collector at Senotay
As a leading mobile dust collector manufacturer in China, Hebei OuTai (Senotay) provides advanced production technology and strict quality assurance:
CNC precision fabrication and laser-cutting technology.
Customized filtration systems for different dust types and industries.
High air volume efficiency with intelligent control options.
Environmentally friendly coatings for durability and corrosion resistance.
Rigorous quality testing before shipment to guarantee long-term performance.
Applications
Welding workshops and fabrication plants.
Chemical, pharmaceutical, and food production facilities.
Woodworking shops and furniture manufacturing.
Powder coating lines and painting booths.
Construction sites and foundries.
FAQs
Q1: What makes a mobile dust collector different from a fixed unit?
Answers: It’s portable and can be moved between working stations without installation needs, making it ideal for flexible production.
Q2: Does Senotay offer customized solutions?
Answers: Yes, we tailor airflow capacity, filter type, and power options according to your specific industrial needs.
Q3: How often should filters be replaced?
Answers: Typically every 6–12 months, depending on usage intensity and dust type.
Q4: Can it handle welding fumes and smoke?
Answers: Absolutely. Senotay’s mobile dust collectors are optimized for both dust and fume extraction.
Q5: What after-sales service do you provide?
Answers: We offer installation guidance, technical support, spare parts, and lifetime service assistance.
