Hebei OuTai Environmental Protection Equipment Co., Ltd FMS Filter Bag
Achieve flawless emissions compliance in the most punishing thermal environments with the SENOTAY FMS (Fluoro-Metamax Structure) Filter Bag Series—the ultimate solution for high-temperature dust collection from Hebei OuTai Environmental Protection Equipment Co., Ltd. (SENOTAY). FMS is a highly engineered composite material that blends distinct premium fibers—typically fiberglass combined with Nomex (Aramid), P84 (Polyimide), or PPS—via needle punching. This specialized composite structure overcomes the structural brittleness of pure glass fibers while delivering exceptional tensile strength, outstanding flex life, and superb resistance to chemical attack.
Engineered to operate continuously at high temperatures, SENOTAY FMS filter bags provide a highly durable, cost-effective alternative to pure synthetic options for heavy industrial baghouses.
Why Leading Plants Choose SENOTAY:
Factory-Direct Pricing. Certified Quality. Dedicated Support.
Best Price Guarantee
Certified & Compliant
Fast, Free Shipping
Comprehensive After-Sales Support
Lifetime Technical Support: Expert assistance with gas chemistry analysis, air-to-cloth ratios, structural cage profiling, and media compatibility for the lifespan of your dust collector.
Full System Availability: Immediate access to matching heavy-duty galvanized, epoxy-coated, or stainless steel filter cages (including star-ring and multi-section configurations).
Remote Troubleshooting: Fast diagnostics to resolve differential pressure alarms, premature thermal degradation, or localized abrasive wear.
Trusted by extreme-heat industrial plants worldwide. Ready for yours.
Why Choose FMS Filter Bags Over Standard Polyester Bags
Superior Temperature Resistance: It Performs reliably up to 260°C or 500°F.
Enhanced Mechanical Strength: The system Resists tearing, abrasion and pulse-jet stress.
Longer Service Life: Lasts 2–3x longer than standard polyester or acrylic filter bags.
Improved Filtration Efficiency: Its internal fnctions Achieves up to 99.9% dust removal in high-load applications.
Stable Performance in Harsh Environments: Ideal for acidic or high-moisture flue gases.
Product Types Table (Standard Configurations)
Our FMS filter bags are available in multiple variants to suit different operational demands.
Model / Type | Weight (g/m²) | Thickness (mm) | Max Temp (°C) | Best For / Application |
FMS-500 | 500 | 1.8 | 240 | General Industrial Filtration |
FMS-550 | 550 | 2.0 | 240 | Cement Plants |
FMS-600 | 600 | 2.2 | 250 | Steel & Metallurgy |
FMS-650 | 650 | 2.4 | 260 | Waste Incineration |
FMS-700 | 700 | 2.6 | 260 | Non-Ferrous Smelting |
FMS-750 | 750 | 2.8 | 260 | Power Generation |
FMS-800 | 800 | 3.0 | 260 | Chemical Processing |
FMS-850 | 850 | 3.2 | 260 | High Dust Load Environments |
FMS-900 | 900 | 3.4 | 260 | High-Temperature Kilns |
FMS-950 | 950 | 3.6 | 260 | Critical Dust Control Systems |
Model FMS Filter Bag Specifications
Model Code | FMS-150×2500 | FMS-150×3000 | FMS-180×2500 | FMS-180×3200 | FMS-200×3000 | FMS-200×4000 | FMS-220×3500 | FMS-220×4500 |
Diameter (mm) | 150 | 150 | 180 | 180 | 200 | 200 | 220 | 220 |
Length (mm) | 2500 | 3000 | 2500 | 3200 | 3000 | 4000 | 3500 | 4500 |
Filter Area (m²) | 1.18 | 1.41 | 1.41 | 1.81 | 1.88 | 2.51 | 2.42 | 3.11 |
Weight (g/m²) | 900 ±20 | 900 ±20 | 900 ±20 | 900 ±20 | 900 ±20 | 900 ±20 | 900 ±20 | 900 ±20 |
Thickness (mm) | 2.2–2.5 | 2.2–2.5 | 2.2–2.5 | 2.2–2.5 | 2.2–2.5 | 2.2–2.5 | 2.2–2.5 | 2.2–2.5 |
Max Continuous Temp (°C) | <200 | <200 | <200 | <200 | <200 | <200 | <200 | <200 |
Tensile Strength (N/5×20cm) | >2000 (warp/weft) | >2000 | >2000 | >2000 | >2000 | >2000 | >2000 | >2000 |
Air Permeability (L/m²/s) | 40–60 | 40–60 | 40–60 | 40–60 | 40–60 | 40–60 | 40–60 | 40–60 |
All models include PTFE surface treatment and reinforced bottom seams. Custom sizes and end caps available.
Core Specification of FMS Filter Bag
product name: | FMS filter bag |
Fiber Type | Coated fiberglass |
Weight (g/ Square meter) | 900± 20 |
Thickness(mm) | 2.2 - 2.5 |
Tensile strength (N/5×20cm) | vertical | >2000 |
Weft | >2000 |
Air permeability (L/m2/s·200pa) | 40-60 |
Recommended operating temperature (℃) | ＜200 |
Instantaneous operating temperature (℃) | ＜260 |
Surface treatment process | PTFE |
Features of FMS Filter Bag: Quality, Value & Expertise
FMS filter bag is a high-performance filtration material, which combines a variety of high-temperature-resistant fibres and is made through a special process, aiming to meet the filtration needs of industrial production for high temperature, corrosion, abrasion and other harsh environments. The following is the detailed introduction of FMS filter bag:
Material Composition: FMS filter bags are usually made of alkali-free glass fibre staple yarn, aramid, P84 and other high-temperature-resistant fibres mixed in a certain proportion. These materials give the filter bag excellent physical and chemical properties.
High Temperature Resistance: FMS filter bags are able to withstand temperatures up to 260 degrees Celsius, with transient temperatures even reaching 300 degrees Celsius. This characteristic enables it to maintain good filtration performance and stability under high temperature environment.
Corrosion resistance: FMS filter bag made of polytetrafluoroethylene (PTFE) membrane material has excellent corrosion resistance. It can resist the erosion of many chemicals, including acids, alkalis, salts and other corrosive substances.
Filtering Efficiency: The filtration efficiency of FMS filter bag can reach more than 99.99%, which can effectively filter tiny particles and harmful gases. Its unique fibre structure and surface area coefficient make the dust mostly concentrated on the surface of the filter media, and it is more difficult to penetrate into the filter media to block the voids.
Wear resistance and folding resistance: P84 fibres are added on the basis of glass fibre needle felt, which makes the felt layer more compact and enhances the entanglement between fibres, thus improving its wear resistance and folding resistance.
Dust-cleaning effect: The surface of FMS filter bag has been specially treated with excellent hydrophobicity and anti-static properties, which is not easy to attach dust and has a better dust-cleaning effect.
Applications: FMS filter bags are widely used in iron and steel, smelting, chemical industry, carbon black, building materials, electric power and other industries, providing efficient dust filtration solutions for these industries.
Economy: Compared with synthetic chemical fibre high temperature resistant filter media, FMS filter bag overcomes the weaknesses of chemical fibre filter media such as large elongation, large deformation, low temperature resistance and poor corrosion resistance, and the price is relatively low.
In short, with its excellent high temperature resistance, corrosion resistance, abrasion resistance and high efficiency filtration efficiency, FMS filter bag plays an important role in industrial production, and is the ideal filtration material for high temperature and corrosive environment.
Key Advantages Explained: Genuine FMS Filter Bags: Precision OEM Replacements for Industrial Dust Collectors
1. Excellent High-Temperature Resistance
The FMS Filter Bag is designed to perform under continuous temperatures up to 260°C that is making it the perfect choice for dust collection in kilns, furnaces and incinerators. Its glass and aramid fiber composition ensures structural stability where standard fabrics degrade.
2. Superior Corrosion and Chemical Resistance
The blend of PPS and glass fibers provides outstanding resistance to acidic gases, alkali attacks and oxidizing environments which is very much ideal for chemical plants and waste treatment facilities.
3. High Filtration Efficiency & Energy Savings
Its fine fiber matrix achieves 99.9% dust removal efficiency while maintaining low pressure drop. This reduces system energy consumption and extends pulse-cleaning intervals that resulting in lower operational costs.
▪ Dust Filter Bag
▪ Polyester Filter Bag | FMS Filter Bag | Basalt Filter Bag | Nomex Filter Bag |
PTFE Filter Bag | Acrylic Filter Bag | Fiberglass Filter Bag | P84 Filter Bag | PPS Filter Bag
▪ Dust Collector Bag Cage
▪ Dust Collector Bag Cage | Galvanized Bag Cage | Silicone Bag Cage | Trapezoidal Bag Cage | Envelope Bag Cage | Cage Venturi Tube
▪ Dust filter element
▪ Air Filter Element | Top-mounted Dust Filter Element | Oblique-insert Dust Filter Element |
Lifting Dust Filter Element | Six-Ear Quick-release Dust Filter Element | Threaded Dust Filter Element | Flange Dust Filter Element
▪ Electromagnetic pulse valve
▪ DMF-Z Right Angle Solenoid Pulse Valve | DMF-Y Submerged Electromagnetic Pulse Valve
▪ Industrial Electric Precipitation Accessories
▪ Cathode Wire | Dust Collecting Plate | Vibrating Hammer | Bearing In Dust | Electrostatic Precipitator Porcelain Sleeve
FMS Filter Bags: Quick FAQ
Q1: What exactly is an FMS filter bag material?
FMS (Fiberglass Mixed Synthetic) is a high-performance composite needle felt. It blends alkali-free glass fibers with high-temperature synthetic fibers (such as P84, Aramid, or PTFE) to overcome the structural brittleness of pure fiberglass while keeping production costs significantly lower than 100% pure synthetic options.
Q2: What is the maximum operating temperature threshold?
FMS filter bags handle a continuous operating temperature of up to 260°C (500°F), with short-term dry-heat surge limits reaching 280°C (536°F). This makes them ideal for blast furnace gas, cement kilns, and waste incineration plants.
Q3: How do FMS composite elements improve on pure fiberglass?
By needling synthetic fibers into the glass matrix, FMS media achieves:
Folding & Wear Resistance: Eliminates fiberglass micro-fracturing from high-frequency pulse-jet flexing.
Higher Airflow: Allows a higher filtering wind speed while maintaining a lower initial running resistance drop (1000 Pa to 1450 Pa).
Q4: What is the chemical resistance profile of FMS bags?
FMS bags expand the chemical window of traditional glass fibers, stably operating across a pH chemical resistance window of pH 1 to pH 12. The inclusion of P84 or PTFE fibers protects the glass cores against aggressive SOx and NOx acid hydrolysis in flue gases.
Q5: Why is P84 often added to the FMS fiber blend?
P84 (polyimide) fibers feature a unique trilobal cross-section. When blended into FMS needle felt, this shape drastically increases the surface area matrix, trapping ultra-fine particulate directly on the surface layer and preventing deep pore blinding.
Q6: What are the standard physical tolerances for FMS bags?
To prevent hazardous dust bypass leaks in heavy-duty baghouses, high-precision factory lines manufacture FMS bags to tight physical tolerances of ±0.5mm on the snap-band cell plate diameter and ±10mm on the overall flat bag length.
Q7: Which surface treatments optimize FMS performance?
PTFE Impregnation / Bath: Coats individual fibers to protect against high-sulfur chemical attack.
ePTFE Membrane Lamination: Achieves ultra-low emissions (<5 mg/Nm³) by restricting filtration strictly to the surface layer.
Q8: What specifications are required to request a B2B factory price quote?
To receive accurate volume pricing for senotay.com inquiries, provide the exact cell plate hole diameter, total flat length, material blend ratio (e.g., Fiberglass + P84), top/bottom connection configurations, and your flue gas chemistry.
